First, the main performance parameters:
1 Nominal pressure:. 0.05MPa, 0.10MPa, 0.25MPa
2. Diameter DN600-DN2600
3 Temperature:. ≤ 200 ℃
4 Medium:
Second, the structural characteristics:
1 valve fully enclosed housing, the media does not leak out during operation, to avoid environmental pollution;
2 valve adopts frame structure, good rigidity, compact structure;
3 sealing parts made of stainless steel with a rubber seal, seal and reliable;
4 flapper valve hydraulic clamping mechanism with spring clamp, electric flapper valve nut clamping screw clamping mechanism adopted, good synchronization.
5 ring mounted on the valve plate, easy to replace.
